OpenStack Heat and os-collect-config

OpenStack-logo

os-collect-config

os-collect-config is a tool that starts up via systemd when a system boots. It initially runs at boot time, but continues to run looking for changes in heat metadata. In a nutshell,  os-collect-config is responsible for monitoring and downloading metadata from the Heat API.

When data changes, os-collect-config makes a call to os-refresh-config. This data provides the node with all of the information it needs to make configuration changes to the host – this data will be node specific.

Os-collect-config polls for data from sources (nova-metadata and heat) and stores them in /var/lib/os-collect-config/.

Example of the contents of the directory above.

-rw——-. 1 root root 42412 Jul 23 14:40 ComputeAllNodesDeployment.json
-rw——-. 1 root root 42412 Jun 4 20:56 ComputeAllNodesDeployment.json.last
-rw——-. 1 root root 35447 Feb 20 2017 ComputeAllNodesDeployment.json.orig
-rw——-. 1 root root 23852 Jul 23 14:40 ComputeHostsDeployment.json
-rw——-. 1 root root 23852 Jun 4 20:07 ComputeHostsDeployment.json.last
-rw——-. 1 root root 8074 Feb 20 2017 ComputeHostsDeployment.json.orig
-rw——-. 1 root root 1071 Jul 23 14:40 ec2.json
-rw——-. 1 root root 1071 Feb 20 2017 ec2.json.last
-rw——-. 1 root root 1071 Feb 20 2017 ec2.json.orig
-rw——-. 1 root root 441 Feb 20 2017 heat_local.json
-rw——-. 1 root root 441 Feb 20 2017 heat_local.json.last
-rw——-. 1 root root 441 Feb 20 2017 heat_local.json.orig
-rw——-. 1 root root 2635 Jul 23 14:40 NetworkDeployment.json
-rw——-. 1 root root 2635 Mar 1 2017 NetworkDeployment.json.last
-rw——-. 1 root root 2636 Feb 20 2017 NetworkDeployment.json.orig
-rw——-. 1 root root 13259 Jul 23 14:40 NovaComputeDeployment.json
-rw——-. 1 root root 13259 Jan 16 2018 NovaComputeDeployment.json.last
-rw——-. 1 root root 11069 Feb 20 2017 NovaComputeDeployment.json.orig
-rw——-. 1 root root 311 Jun 4 22:02 os_config_files.json
-rw——-. 1 root root 252762 Jul 23 14:40 request.json
-rw——-. 1 root root 252762 Jun 4 22:07 request.json.last
-rw——-. 1 root root 23440 Feb 20 2017 request.json.orig

Example of the contents of the directory above. You will usually find 3 versions of each config. Current, original, and last (previous).

You can view this metadata, using python, as shown below.

# python -m json.tool ComputeAllNodesDeployment.json
{
“hiera”: {
“datafiles”: {
“all_nodes”: {
“mapped_data”: {
“ca_certs_enabled”: “true”,
“ca_certs_short_node_names”: [

…trunc…

os-refresh-config

os-refresh-config is called by os-collect-config once it recognizes that metadata has changed within the Heat API for that specific node.

The important steps that os-refresh-config take are shown below

1) Apply systemctl configurables
2) Run os-apply-config (see below)
3) Configure the networking for the host
4) Download and set the hieradata files for puppet parameters
5) Configure /etc/hosts
6) Deploy software configuration with Heat

os-apply-config

os-apply-config is called by os-refresh-config to sets up configuration files on specific nodes. It is called via ‘/usr/libexec/os-refresh-config/configure.d/20-os-apply-config‘.

As is does with the undercloud deploy, os-refresh-config executes scripts under /usr/libexec/os-refresh-config/ in a specific order based on numbering.

First scripts within thje  pre-configure.d/ directory are run, then configure.d/ scripts are applied, and finally scripts in post-configure.d/.

It is within these scripts that the metadata downloaded by os-collect-config will be acted upon.

Any call to os-apply-config uses the files in /var/lib/os-collect-config as its configuration source.

The appropriate script files for doing so are as follows:

overcloud$ ll /usr/libexec/os-refresh-config/configure.d/
total 32
-rwxr-xr-x. 1 root root 396 Aug 5 07:31 10-sysctl-apply-config
-rwxr-xr-x. 1 root root 42 Aug 5 07:31 20-os-apply-config
-rwxr-xr-x. 1 root root 189 Aug 5 07:31 20-os-net-config
-rwxr-xr-x. 1 root root 629 Aug 5 07:31 25-set-network-gateway
-rwxr-xr-x. 1 root root 2265 Aug 5 07:31 40-hiera-datafiles
-rwxr-xr-x. 1 root root 1387 Aug 5 07:31 51-hosts
-rwxr-xr-x. 1 root root 5784 Aug 5 07:31 55-heat-config

If we run os-apply-config manually, we can see that it does the following:

overcloud$ sudo sh /usr/libexec/os-refresh-config/configure.d/20-os-apply-config
[2015/08/07 01:17:40 PM] [INFO] writing /etc/os-net-config/config.json
[2015/08/07 01:17:40 PM] [INFO] writing /var/run/heat-config/heat-config
[2015/08/07 01:17:40 PM] [INFO] writing /etc/puppet/hiera.yaml
[2015/08/07 01:17:40 PM] [INFO] writing /etc/os-collect-config.conf
[2015/08/07 01:17:40 PM] [INFO] success



os-net-config

The directory /os/net-config/ holds the config.json file that is used to modify the networking configuration on each host. The config found in this file is derived from the os-collect-config data in /var/lib/os-collect-config/.

Again you can use this file to review your networking configuration and compare and contrast to your templates. Formatting is off in the file below, but you get the point.
# python -m json.tool config.json
{
“network_config”: [
{
“addresses”: [
{
“ip_netmask”: “172.20.4.113/24”
}
],
“dns_servers”: [
“96.239.250.57”,
“96.239.250.58”
],
“name”: “em3”,
“routes”: [
{
“ip_netmask”: “169.254.169.254/32”,
“next_hop”: “172.20.4.20”
}
],
“type”: “interface”,
“use_dhcp”: false
},
{
“members”: [
{
“bonding_options”: “mode=4 lacp_rate=1 updelay=1000 miimon=50”,
“members”: [
{
“mtu”: 9216,
“name”: “em1”,
“primary”: true,
“type”: “interface”
},
{
“mtu”: 9216,
“name”: “em2”,
“type”: “interface”
}
],
“mtu”: 9216,
“name”: “bond1”,
“type”: “linux_bond”
},
{
“addresses”: [
{
“ip_netmask”: “172.20.3.30/24”
}
],
“device”: “bond1”,
“mtu”: 9000,
“type”: “vlan”,
“vlan_id”: 52

OpenStack: Introduction to Troubleshooting Heat

keyboard-key-board-melt-broken-computer_p

Introduction to Heat

Heat is the main orchestration engine for OpenStack, and is used my OpenStack director to install an OpenStack Overcloud environment.

When we run the “openstack deploy overcloud” command, we are specifically
telling RHEL OSP director that we want it to use the pre-defined Heat templates from
/usr/share/openstack-tripleo-heat-templates/. OSP director will manage the
deployment of a new overcloud heat stack, using files from this directory.
When RHEL OSP director calls the Heat stack, it needs the following data…

  • A top-level Heat template to use that describes the overall environment and the
    resources required.
  • An environment/resource registry to tell Heat where to find resource
    definitions for non-standard Heat elements, e.g. TripleO components.
  • A set of parameters to declare the deployment-specific options (via -e)



The most important files for us to focus on are in our deployment directory, these are the default files that get called by OSP director.

  • The top-level Heat template that OSP director uses for deployment is
    /usr/share/openstack-tripleo-heat-templates/overcloud-without-mergepy.yaml
  • The resource registry, which tells Heat where to find the templates for
    deployment resources is
    /usr/share/openstack-tripleo-heat-templates/overcloud-resource-registry-puppet.
    yaml

Creating a Heat Stack

To create the stack we run the command below. This command instructs heat to use
the templates in ~/my_templates/, as well as the override templates specified
with the ‘-e’ option.

This is just an example of what I am using in my lab environment, your deploy command will be much different. Also note that I have copied the templates from /usr/share/openstack-tripleo-heat-templates to ~/my_templates/.

#openstack overcloud deploy –debug –templates ~/my_templates/ \
–ntp-server 10.1.0.1 –control-scale 3 –compute-scale 2 \
-e ~/my_templates/advanced-networking.yaml

Troubleshooting a Failed Heat Stack

Unfortunately our deploy failed with the following errors.

Exception: Heat Stack create failed.
DEBUG: openstackclient.shell clean_up DeployOvercloud
DEBUG: openstackclient.shell got an error: Heat Stack create failed.
ERROR: openstackclient.shell Traceback (most recent call last):
File “/usr/lib/python2.7/site-packages/openstackclient/shell.py”, line 176, in
run
return super(OpenStackShell, self).run(argv)
File “/usr/lib/python2.7/site-packages/cliff/app.py”, line 230, in run
result = self.run_subcommand(remainder)
File “/usr/lib/python2.7/site-packages/cliff/app.py”, line 295, in
run_subcommand
result = cmd.run(parsed_args)
File “/usr/lib/python2.7/site-packages/cliff/command.py”, line 53, in run
self.take_action(parsed_args)
File
“/usr/lib/python2.7/site-packages/rdomanager_oscplugin/v1/overcloud_deploy.py”,
line 864, in take_action
self._deploy_tripleo_heat_templates(stack, parsed_args)
File
“/usr/lib/python2.7/site-packages/rdomanager_oscplugin/v1/overcloud_deploy.py”,
line 535, in _deploy_tripleo_heat_templates
parsed_args.timeout)
File
“/usr/lib/python2.7/site-packages/rdomanager_oscplugin/v1/overcloud_deploy.py”,
line 478, in _heat_deploy
raise Exception(“Heat Stack create failed.”)
Exception: Heat Stack create failed.

We can verify that the deploy failed with the command below.

stack@undercloud] # heat stack-list
+————————————–+————+—————+—| id | stack_name | stack_status | creation_time |
+————————————–+————+—————+—
| ce993847-b0ee-4ea2-ac15-dc0ddc81825a | overcloud | CREATE_FAILED |
2016-02-29T20:40:54Z |

Since the stack deploy has failed, let’s take a closer look at the stack resources
and see if we can determine which resources failed.

Here we will make things simple by viewing only failed resources.

[stack@undercloud] # heat resource-list overcloud | grep -i failed
| Compute | c032c668-755f-422f-8ad1-4abf46b022ff
| OS::Heat::ResourceGroup | CREATE_FAILED |
2016-02-29T20:40:55Z |
| Controller | 668d27e0-9ab1-4dbe-8445-1d1ee8839265
| OS::Heat::ResourceGroup | CREATE_FAILED |
2016-02-29T20:40:55Z |

The failed resources are named “Compute” and “Controller“. Lets take a closer
look at those using the “resource-show” argument.

#heat resource-show overcloud Compute

| resource_status_reason | ResourceUnknownStatus: Resource failed – Unknown
status FAILED due to “Resource CREATE failed: ResourceUnknownStatus:
Resource failed – Unknown status FAILED due to “Resource CREATE failed:
StackValidationFailed: Property error : OsNetConfigImpl: config The Parameter
(BondInterfaceOvsOptions) was not provided.”” |

Let’s now do the same for Controller.

#heat resource-show overcloud Controller

| resource_status_reason | ResourceUnknownStatus: Resource failed – Unknown
status FAILED due to “Resource CREATE failed: ResourceUnknownStatus:
Resource failed – Unknown status FAILED due to “Resource CREATE failed:
StackValidationFailed: Property error : OsNetConfigImpl: config The Parameter
(BondInterfaceOvsOptions) was not provided.”” |

Apparently I have some issues with my OVS bonding options, so I need to get those straight before I can continue.

Deleting a Failed Heat Stack

Since our last deploy failed, we need to delete the failed stack before we can kick off another stack deploy. Below is an example of that command – note we are using the UUID of the stack.



[stack@vz-undercloud] # heat stack-delete 2b0da4f6-e6f8-41cd-89e8-bf070d0e0d15
 +--------------------------------------+------------+-------------------| id | stack_name | stack_status | creation_time |
 +--------------------------------------+------------+-------------------
 | 2b0da4f6-e6f8-41cd-89e8-bf070d0e0d15 | overcloud | DELETE_IN_PROGRESS |
 2016-03-01T17:21:58Z |
 +--------------------------------------+------------+-------------------

then…

[stack@vz-undercloud] # heat stack-list
 +--------------------------------------+------------+---------------+---
 | id | stack_name | stack_status | creation_time |
 +--------------------------------------+------------+---------------+---
 | 2b0da4f6-e6f8-41cd-89e8-bf070d0e0d15 | overcloud | DELETE_FAILED |
 2016-03-01T17:21:58Z |
 +--------------------------------------+------------+---------------+---

Now lets kick off another deploy

#openstack overcloud deploy –debug –templates ~/my_templates/ \
–ntp-server 10.1.0.1 –control-scale 3 –compute-scale 2 \
-e ~/my_templates/advanced-networking.yaml

Unfortunately, this deploy failed as well.

Ok, let’s take a look at /var/log/heat/heat/heat-engine.log for more details. I also suggest opening another ssh session and tailing the log while the delete is attempting to do its thing.

If the output is too verbose to follow, I suggest attempting to thin out the output using the command below

#tail -f /var/log/heat/heat-engine.log | egrep ‘error|fatal’

This lead me to the following error.

2016-03-01 13:46:12.366 18554 ERROR heat.engine.resource [-] Error marking
resource as failed
2016-03-01 13:46:12.366 18554 TRACE heat.engine.resource DBConnectionError:
(_mysql_exceptions.OperationalError) (2003, “Can’t connect to MySQL server on
‘172.16.0.10’ (111)”)

Mysql is down? So now we need to look at the mariadb logs – where we see the following.

160301 12:16:24 [Warning] Failed to setup SSL
160301 12:16:24 [Warning] SSL error: SSL_CTX_set_default_verify_paths failed

Apparently SELinux is blocking the reads for the certificates.
There are two ways to work around this issue. You can run “restorecon -v
/path/to/certs/“, or you can work around by disabling selinux by running
“setenforce 0” or by editing the /etc/selinux/config file and setting ‘SELINUX=DISABLED’.
You may need to rerun the delete, in my case it was stuck in
“DELETE_IN_PROGRESS”.  I restarted all heat releated services to force the delete to error.

#systemctl restart openstack-heat-engine.service openstack-heat-api.service
openstack-heat-api-cloudwatch.service openstack-heat-api-cfn.service

This will cause the delete to error. You can then retry the delete.

If the delete is taking a long time, you can dig a bit deeper into the delete
using the command below.

#heat resource-list overcloud

Now drill down more with the command below.

#heat event-list overcloud

Make note of the resource_name and its id and use them in the next command.
Note that stack name is still overcloud.

heat event-show overcloud Compute d9e13b02-07b0-4beb-8442-f25de0e7ef8b

I have found that rebooting the undercloud will clear out any in-progress
tasks, you can then run the delete again.

You can also try to manually delete each node from Ironic by mimic’ing what the
nova driver in Ironic does. This is shown below for reference.

$ ironic node-set-provision-state <node uuid> deleted

And to remove the instance_uuid

$ ironic node-update <node uuid> remove instance_uuid

Troubleshooting Failed and In Progress Deployments.

Updated 6/28/2018

While your deploy is running, you can watch for stuck or failed deployments.

$ heat deployment-list | grep -vi complete
WARNING (shell) "heat deployment-list" is deprecated, please use "openstack software deployment list" instead
+--------------------------------------+--------------------------------------+--------------------------------------+--------+-------------+----------------------+------------------+
| id | config_id | server_id | action | status | creation_time | status_reason |
+--------------------------------------+--------------------------------------+--------------------------------------+--------+-------------+----------------------+------------------+
| 143b25ce-9c1e-48b0-bd92-2569640b5208 | 5b9843a5-2092-4c75-8eae-2e042d7b34d2 | f08232e7-7a14-4885-86ab-443b4581afe6 | CREATE | IN_PROGRESS | 2017-05-17T19:46:38Z | None |
| 27d2a61e-e5cd-4313-967d-cc7c385320cb | c113ead1-bb9a-46ca-a992-4527c2e9fda1 | 67dc5457-5ae7-4290-ad77-36bf8bc81d56 | CREATE | IN_PROGRESS | 2017-05-17T19:46:38Z | None |
| fabab6ae-8848-4a35-8066-d83f82335e95 | 763c4760-3e8c-43c1-8afd-d1b8d6bbb55b | e51061ed-f96f-43ec-b18a-4dc079d961d8 | CREATE | IN_PROGRESS | 2017-05-17T19:46:38Z | None |
| 0b6993c1-a320-4dc7-980c-e789d87a0c84 | 50f1e303-123a-451b-9d86-f29c32e6ce0b | 8d87818a-943f-4f69-8112-7450dfa26bb7 | CREATE | IN_PROGRESS | 2017-05-17T19:46:39Z | None |
| 0e537823-f17d-4009-b2e4-6d11adcdfeb7 | 1d7938ad-a6e5-4d8f-9604-489408295a59 | 98847475-ed1c-44b2-aa4e-bbddfe81a1d1 | CREATE | IN_PROGRESS | 2017-05-17T19:46:39Z | None |
| 1d89b9cf-87cf-4050-a00f-496c82fd9432 | 4f378bc3-10a7-4a47-b269-2c7de5d75dd7 | 69257ad8-a3ee-453b-a532-db3c293a34b9 | CREATE | IN_PROGRESS | 2017-05-17T19:46:39Z | None |
| 3d5915a6-1470-4ffe-a0f1-a356df33e1f9 | dbc8c62c-f5cc-4cfa-93af-ef7b9f02fd19 | 75b49872-c1fb-4c83-87d1-579dcd027bc8 | CREATE | IN_PROGRESS | 2017-05-17T19:46:39Z | None |
| a2e57b50-dc03-42a8-b851-b33ade36d591 | 0c7133d8-20bc-481d-b9c5-2d0867a656e7 | 000794e9-4ce2-4c8a-aa69-02aadfd19ce6 | CREATE | IN_PROGRESS | 2017-05-17T19:46:39Z | None |
| ab463b0f-fd6e-4169-9283-3e8bbcc1bb4b | 627f1288-3823-4e21-b61d-4bafcbdc446a | b6cf41e8-e60c-43ca-a3ed-d24c078031c8 | CREATE | IN_PROGRESS | 2017-05-17T19:46:39Z | None |
| ad05853f-2e70-4f11-b8c0-26d2d4c324fb | 8cd656e7-129f-40d4-a1bc-ed0181b9e768 | 24017696-102d-43ab-a101-f3a33a091faa | CREATE | IN_PROGRESS | 2017-05-17T19:46:39Z | None |
| b6418aec-385a-4b6f-845b-84c87fa10be7 | 04747e35-f0cc-45a4-b251-78ea61a08c83 | ffe36a72-2293-48eb-93ed-bfe1077a0245 | CREATE | IN_PROGRESS | 2017-05-17T19:46:39Z | None |
| e741d37d-6119-4d37-8b91-519ecfad8397 | 271139d7-c29c-47df-ad11-26bbc3373c4c | 167dc5ee-0831-4fa8-a7ca-8db6d2b3d4ea | CREATE | IN_PROGRESS | 2017-05-17T19:46:39Z | None |
| 0910d714-027b-40b0-acf3-140f5ab90837 | 9317c6ca-b767-49f2-a56c-45b61bbee2d5 | 34f6b4fd-fa98-46b6-8ace-b6f76af50162 | CREATE | IN_PROGRESS | 2017-05-17T19:46:40Z | None |
| 508e585d-19ec-41e8-bc1e-049d8206f614 | 0917bf21-54f8-46ce-89c8-6461001840a5 | c8aa01f8-5627-46a4-885c-dc61e0886c09 | CREATE | IN_PROGRESS | 2017-05-17T19:46:40Z | None |
+--------------------------------------+--------------------------------------+--------------------------------------+--------+-------------+----------------------+------------------+

Next I can inspect a stuck/hung deployment using the command below.  Note that server id above directly corresponds to a nova uuid.

$ heat deployment-show 05d3c2b7-104c-47fd-beeb-3819d55aafb7
WARNING (shell) "heat deployment-show" is deprecated, please use "openstack software deployment show" instead
{
 "status": "COMPLETE",
 "server_id": "e1389b2e-ae2c-4095-8654-fd1cac1a8563",
 "config_id": "1bfd85e8-217c-440f-b095-f4a2fcce4bfc",
 "output_values": {
 "deploy_stdout": "ssh-rsa AAAAB3NzaC1yc2EAAAADAQABAAABAQDVWznMhZnwFKR9KH+7ppJr5f7ZI2LsxwZV6+xPkNOhNE5o2DDNGWGVoGE+2SIiENuhk938LRUixg4pj1coXl9johjv8h2PcB+6rUxVT7jSKGUdpwgTlLsNOEugcR5oJjf0mM55BMzz1nr1yZMTy9THGwU/A43RZcOVvuJXFVA3MIlYGXXUidEOQM6NMEloUpVd/hj2BXUzdaUJV83E0aSGPvED02LixV5uorY0n4OIk2EXC8LlG0863YwJEdQi7hd8/rczLwX18CFFAQJ2mOwkcuJB37V/BEWUqBczHO46e0uc1ZmHhtdPFKgFObgP8gSrT4g0HjOds/BVPgBTtQf5 tripleo-validations\n",
 "deploy_stderr": "",
 "deploy_status_code": 0
 },
 "creation_time": "2017-05-17T19:46:38Z",
 "updated_time": "2017-05-17T19:49:26Z",
 "input_values": {},
 "action": "CREATE",
 "status_reason": "Outputs received",
 "id": "05d3c2b7-104c-47fd-beeb-3819d55aafb7"

Deleting a Zombie Overcloud

Sometimes it is impossible to delete a failed deploy. After attempting a deploy the stack was stuck in the state below.

+--------------------------------------+------------+--------------------+----------------------+----------------------+
| id | stack_name | stack_status | creation_time | updated_time |
+--------------------------------------+------------+--------------------+----------------------+----------------------+
| 34fa8bd8-b80b-4379-925f-26465e366da7 | overcloud | DELETE_IN_PROGRESS | 2018-07-06T15:58:09Z | 2018-07-06T16:15:57Z |

I was given this command to kill it

# openstack stack list --nested --column ID --format value | xargs openstack stack delete --yes

This finally allowed the stack to delete.

[stack@tpavcpp4r1v4uc ~]$ heat stack-list
WARNING (shell) "heat stack-list" is deprecated, please use "openstack stack list" instead
+----+------------+--------------+---------------+--------------+
| id | stack_name | stack_status | creation_time | updated_time |
+----+------------+--------------+---------------+--------------+
+----+------------+--------------+---------------+--------------+

If you run into the error below when attempting to redeploy

Exception creating plan: Unable to create plan. The Mistral environment already exists

You will need to run the command below to delete the mistral plan

#openstack overcloud plan delete overcloud

Additional Resources

https://wiki.openstack.org/wiki/Heat

http://hardysteven.blogspot.com/2015/04/debugging-tripleo-heat-templates.html



Linux: How to start a Minecraft server at boot via Systemd

index-hero-og.088fb7996b03

I am not into Minecraft, but my kids are.

I decided to local host a small Minecraft server on a RHEL 7 vm.  There are tons of guides on how to install Minecraft on Linux, but I did not find much of anything that details how to get the software to start at boot-time via systemd.

Below are the steps that I took. These instructions should work on RHEL 6/7, Centos 6/7, or any other Linux that utilizes systemd for starting services.

Change directory to the systemd directory.

# cd /etc/systemd/system

Create a systemd service file using your favorite text editor. Mine is called minecraft.service.

[root@minecraft system]# cat minecraft.service
[Unit]
Description=Start Minecraft
After=network.target

[Service]
Type=simple
ExecStart=/root/start_minecraft_server.bash
TimeoutStartSec=0

[Install]
WantedBy=default.target

Make the systemd script executable.

# chmod +x /etc/systemd/system/minecraft.service

Next, create a startup script. Again use your favorite text editor. In the example above, systemd is configured to run the script “/root/start_minecraft_server.bash”. We now need to create that script. Its contents are below.

#!/bin/bash

#Standard Minecraft
cd /home/mcserver/minecraft
exec java -Xmx2048M -Xms2048M -jar minecraft_server.1.12.2.jar nogui

Make the script above executable.

#chmod +x /root/start_minecraft_server.bash

Now reload systemd.

# systemctl daemon-reload

Enable and start your service

#systemctl enable minecraft.service

#systemctl start minecraft.service

RHEL OSP 10/11 – OVS+DPDK Tunables

93905-6a00e551c39e1c883401a511e32c88970c-pi

Tunables for Dell R630s for use when deploying OVS+DPDK


# OSP 10/11 DPDK Tunables
#
# R630 NUMA locality - CPUs
# node 0 cpus: 0 2 4 6 8 10 12 14 16 18 20 22
# 24 26 28 30 32 34 36 38 40 42 44 46
#
# node 1 cpus: 1 3 5 7 9 11 13 15 17 19 21 23
# 25 27 29 31 33 35 37 39 41 43 45 47
#
#
# R630 NUMA locality - NIC
# node 0 dpdk interface - p3p1
# node 1 dpdk interface - p1p1
#
#
#
# NovaVcpuPinSet (OSP 10+)
# These are the cores that Nova will use for scheduling instances. Pair sibling threads together.
# Using cores from NUMA node 0 only to prevent crossing NUMA boundaries
NovaVcpuPinSet: "'4,6,8,10,12,14,16,18,20,22,28,30,32,34,36,38,40,42,44,46'"
#
# NeutronDpdkCoreList (OSP 10/11) OvsPmdCoreList (OSP 12+)
# This parameter configures a list of CPU cores to be used by the OVS-DPDK Poll Mode Drivers
# The first core from a CPU, should be reserved for host processes, and should be excluded from this list.
NeutronDpdkCoreList: "'2,26,3,27'"
#
# HostIsolatedCoreList (OSP 10/11) IsolCpusList (OSP 12+)
# A set list or range of cores (and their sibling threads) to be appended to the tuned cpu-partitioning profile and isolated from the host.
# These cores will be isolated from any host processes
# Assuming you want to isolate nova cores from all system processes, NovaVcpuPinSet + NeutronDpdkCoreList = HostIsolatedCoreList
HostIsolatedCoreList: "'2,3,4,6,8,10,12,14,16,18,20,22,26,27,28,30,32,34,36,38,40,42,44,46'"
#
# HostCpusList (OSP 10/11) & OvsDpdkCoreList (OSP 12+)
# A list of logical cores used by OVS-DPDK processes for dpdk-lcore-mask for non-datapath operations
# These cores must be mutually exclusive from the list of cores in NeutronDpdkCoreList/OvsPmdCoreList and NovaVcpuPinSet.
# Allocate the first physical core (and sibling thread) from each NUMA node irrespective of DPDK interface NUMA locality.
HostCpusList: "'0,24,1,25'"
#
# Provide the number of memory channels in the format - [allowed_pattern: "[0-9]+"]:
NeutronDpdkMemoryChannels: "4"
#
# Set the memory allocated for each socket:
NeutronDpdkSocketMemory: "'2048,2048'"
#
# An array of filters used by Nova to filter a node.These filters will be applied in the order they are listed,
# so place your most restrictive filters first to make the filtering process more efficient.
NovaSchedulerDefaultFilters: "RamFilter,ComputeFilter,AvailabilityZoneFilter,ComputeCapabilitiesFilter,ImagePropertiesFilter,PciPassthroughFilter,NUMATopologyFilter"
#
# Kernel arguments for Compute node
ComputeKernelArgs: "default_hugepagesz=1GB hugepagesz=1G hugepages=32 iommu=pt intel_iommu=on"



How to disable Cloud-Init in a RHEL Cloud Image

happy_cloud1600

So this one is pretty simple. However, I found a lot of misinformation along the way, so I figured that I would jot the proper (and most simple) process here.

Symptoms: a RHEL (or variant) VM that takes a very long time to boot. On the VM console, you can see the following output while the VM boot process is stalled and waiting for a timeout. Note that the message below has nothing to do with cloud init, but its the output that I have most often seen on the console while waiting for a VM to boot.

[106.325574} random: crng init done

Note that I have run into this issue in both OpenStack (when booting from external provider networks) and in KVM.

Upon initial boot of the VM, run the command below.

touch /etc/cloud/cloud-init.disabled

Seriously, that’s it. No need to disable or remove cloud-init services. See reference.





OpenStack 10 (Newton) Lab Installation and Configuration Guide

How to deploy a simple OSP 10 POC/lab environment using Packstack (non-director deploy.

Source: OpenStack 10 (Newton) Lab Installation and Configuration Guide

How to Install TestPMD on RHEL 7.x

dpdk (1).png

TestPMD is a lightweight application running in user space, utilizing ovs-dpdk, that can be used for testing DPDK in packet forwarding mode.

In this example we want to setup TestPMD on a RHEL VM running in our SR-IOV capable Red Hat OpenStack 10 overcloud. Our passthrough adapters are Intel X520s. Our plan here is to run performance tests via an external load generator.

Before we can get started we need to build a test VM.

VM Details

  • RHEL 7.x
  • Two VFs
    • eth0 – ssh access via admin network
    • eth1 – load generator private network
  • 4 vCPUs
  • 4096 MB Mem
  • 150 GB Disk

Deploy RHEL VM

Your first step is to deploy your RHEL VM, configure your primary network interface (eth0 for ssh) via VM console. Eth1 needs to be up and configured to start at boot, but do not assign it an IP address. Next, register your VM with your local satellite server or with RH CDN.

Download DKDP

Use the link below to download the “Latest Major” version of DPDK. Place the tarfile in /root on the VM and untar.

Install Prerequisites

Before we can compile DPDK, we need to install a few prereqs.

Install gcc

#yum -y install gcc

Install lubnuma-devel

#yum -y install glibc-devel

Install Kernel Headers and Devel

#yum -y install kernel-headers.x86_64 kernel-devel.x86_64

Install NUMA Packages

#yum -y install numad.x86_64 numactl-libs.x86_64 numactl-devel.x86_64

Install libpcap

#yum -y install libpcap.x86_64 libpcap-devel.x86_64

Install Tuned Profiles

#yum -y install tuned-profiles-cpu-partitioning.noarch

Install DPDK Tools Package

#yum -y install dpdk-tools.x86_64

Compile DPDK

Compile using the “Quick Start” guide below
http://dpdk.org/doc/quick-start

Determine the PCI address of your test interface using ethtool.

# ethtool -i eth1
driver: ixgbevf
version: 1.5.10-k
firmware-version: 5.02 0x80002390 1.1313.0
expansion-rom-version:
bus-info: 0000:00:05.0
supports-statistics: yes
supports-test: yes
supports-eeprom-access: yes
supports-register-dump: yes
supports-priv-flags: yes

Here the PCI address for eth1 is 0000:00:05.0

Load DPDK Driver for Testing Interface

In this test we are using the Intel x520 NIC, which is directly accessible to our VM via SR-IOV passthrough. If you are passing through a different NIC, your process will differ.

#modprobe vfio-pci
#dpdk-devbind –bind=vfio-pci 0000:00:05.0

Verify Driver using dpdk-devbind

# dpdk-devbind –s

Network devices using DPDK-compatible driver
============================================
0000:00:05.0 ‘82599 Ethernet Controller Virtual Function’ drv=igb_uio unused=ixgbevf,vfio-pci

Network devices using kernel driver
===================================
0000:00:03.0 ‘Virtio network device’ if=eth0 drv=virtio-pci unused=virtio_pci,igb_uio,vfio-pci *Active*

Example TestPDM Start Script

In the example script below, we are going to start TestPDM. By default, TestPDM will forward any packets recieved on eth1 back to the sending MAC

#!/bin/bash

#VARS
NICADDRESS1=’0000:00:05.0′

/root/dpdk-17.08/build/app/testpmd -l 0,1,2,3 –socket-mem 512 -n 4 –proc-type auto –file-prefix pg -w $NICADDRESS1 — –disable-rss –nb-cores=2 –portmask=1 –rxq=1 –txq=1 –rxd=256 –txd=256 –port-topology=chained –forward-mode=macswap -i –auto-start

The example below works for testing an MTU up to 9200 bytes

#works for 9200 byte packet
/root/dpdk-17.08/x86_64-native-linuxapp-gcc/app/testpmd –log-level 8 –huge-dir=/mnt/huge -l 0,1,2,3 -n 4 –proc-type auto –file-prefix pg -w $NICADDRESS1 — –disable-rss –nb-cores=2 –portmask=1 –rxq=2 –txq=2 –rxd=256 –txd=256 –port-topology=chained –forward-mode=mac –eth-peer=0,00:10:94:00:00:06 –mbuf-size=10240 –total-num-mbufs=32768 –max-pkt-len=9200 -i –auto-start



TestPMD has a plethora of options.

For additional information on the options used above, refer to the user guide.

Additional Resources
